PETROL GENERATORS
SPG-3500I
The SPG-3500I model is a single cylinder, vertical, 4-stroke, air-cooled, direct-injection diesel engine. It operates at a frequency of 50Hz and has a maximum output of 4.5 horsepower at 3600 RPM. The rated output of the engine is 3 kilowatts.It has a voltage output of 220V and a DC output of 12V at 8.3 amps. The power factor of the engine is 1, and it has a self-excitation system.
The displacement of the engine is 212 cc, with a bore and stroke of 70x55 mm. The maximum output of the engine is again 4.5 horsepower at 3600 RPM.The engine can be started using either a recoil starter or a self-starter. It has a TCI (Transisterized Pointless) ignition system.The engine has a lube oil capacity of 0.6 liters, with a built-in oil alert system. The dimensions of the engine are 605x465x535 mm, and it weighs 45kg.It has a fuel tank capacity of 10 liters and is equipped with non-fuse overcurrent protection and inverter overcurrent protection program control.
| Model | SPG-3500I |
|---|---|
| Type | Single Cylinder,Verticle ,4 Stroke , Air Cooled, D.I. Diesel Engine |
| Frequency (HZ) | 50 |
| Max.Out put(HP/RPM) | 4.5/3600 |
| Rated out put (KW) | 3 |
| Voltage (v) | 220 |
| DC Out Put | 12Vx8.3A |
| Power Factor | 1 |
| Excitaion System | Self - Excitation |
| Displacement | 212 cc |
| Bore X Stroke (MM) | 70x55 |
| Max.Out put(RPM/HP) | 4.5/3600 |
| Starting System | Recoil Starter / Self Starter |
| Lgnition System | TCI ( Transisterized Pointless) |
| Lube Oil Capacity (ltr) | 0.6 |
| Oil Alert | Built In |
| Dimension LxWxH(mm) | 605X465X535 |
| Weight | 45kg |
| Fuel Tank Capacity | 10 |
| Overload Protection Type | Non-fuse over current protector invertor over current protection program control |
